Epson EB-E10 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 150 Revision A
3.5.10 Service tool list
The following table describes the link of the basic operation manuals and the function about the service tools at 3.5.9 The service tools and the adjustment tasks list
which required before and after parts replacement (p148).
Optical engine --- ---
Take the DR data from the "Intramart" data base. (Intramart)
" 3.5.10 Service tool list (p150)"
Write the DR data of Optical Engine to the MA Board. (CAT)
" 3.6 Writing the DR Data (p152)"
*2: Calibrate on for (Screen Fit/Frame Fit/Easy setup).** Non-applied for this model.
Perform the Panel Alignment. **
" 3.8 LCD Alignment (p162)"
Lamp --- --- Initialize the Lamp information. (AS menu)
" 4.1.3 Initializing (Resetting) (p190)"
Replaced part name
Power on
was possible/
impossible
Before/after
replacement
Required adjustment tasks (service tools name) Reference for the tasks
Tool Name
Necessary to
update
Function
Basic operation manuals
TI-No Reference File name
IPS Tool
Referring to the projector
information.
Obtaining the AS menu information.
AP14-0916-01
Tech Exchange TI
(Utilty/Tool)
IPS-Tool_Manual(E).xlsx
Writing the projector IPS-
Tool_Manual
(E).xlsxinformation.
Reading out the lamp operation time from the MA
Board.
Writing the lamp operation time to the MA Board.
Updating firmware. Writing the firmware to the LCP.
CAT o
Reading the DR data from the old MA Board ofa failed
LCP and save them as file on PC.
Writing the DR-data from PC to the new MA Board
ofthe LCP.
AP08-0912E
Tech Exchange TI
(Utilty/Tool)
SERVICE_TOOL_MANUAL_E_*.
pdf
Intra-mart Delivery system for the DR data. AP08-0912E
Tech Exchange TI
(Utilty/Tool)
RESCUE o Set the destination. RE001
Tech Exchange TI
(Utilty/Tool)
USB firmware for updater Writing the firmware to the LCP by USB or USB cable.
Tech Exchange TI
(General)
Firmware Ver.**(bin file) release for
USB Updater
Easy MP Network firmware for updater
Firmware
Updating the firmware of the LCP by wire network.
Tech Exchange TI
(General)
Firmware Ver.**(bin file) release for
EasyMPNetwork Update
