3.3.2 Lamp
DISASSEMBLY PROCEDURE
1. Loosen the screw ( ) and remove the "Lamp Cover".
2. Loosen the two screws and remove the "Lamp Assy".
Lamp Assy
SCREW,LAMP;3X6
Lamp Cover
