Epson EB-E10 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 66 Revision A
3.1.4 Tools
The following table indicates the tools recommended for use for disassembly,
reassembly and adjustment.
3.1.4.1 Tool List
*1: q.s.: Sufficient quantity
*2: Usable item = “Grease G-78 (AQUADRY W-0082)”
3.1.4.2 Recommended Tool List
Tool Name Qt. Availability Application
Phillips screwdriver No. 00
(8 cm)
1

Disassembling the Focus Ring
and the zoom ring.
Phillips screwdriver No. 1
(10 cm)
1

Disassembling the outer cases
and inner components.
Phillips screwdriver No. 2
(10 cm)
1

Disassembling the outer cases
and inner components.
Hexagonal box screwdriver
(5 mm)
1

Removing the computer
interface
Flat-head precision screwdriver 1 Disassembling the Front Foot
Gloves 1

Anti-static wrist band 1

Be sure to wear them when
handling circuit boards or
Optical Engine.
Tweezers 1

Polyimide tape q.s.*
1

Securing cables.
Use commercially available
Polyimide tape generally called
“KAPTON
®
TAPE”.
Brush 1

Cleaning away dust.
Vacuum cleaner 1

Cleaning away dust.
Lens cleaner
(nonwoven cloth)
q.s.*
1

Cleaning the projection lens.
Lubricant*
2
q.s.*
1
Lubricating the shutter and its
frame.
Projection screen 1

To project images on.
Genuine power cable 1

Genuine remote controller 1

Insulation ohmmeter for
insulation resistance test
1

Rating: 500 V/100 MW
Multi meter 1

Ground continuity check
Air compressor or hand blower 1

To remove dusts from optical
parts and air filter.
Host computer 1

To output audio and video data
to the projector (To check the
component video input).
To control service tools
PC cable 1

Video equipment 1

To output audio and video data
to the projector (To check the
HDMI input).
Audio and Video cables
(HDMI/Composite/USB, and
each audio)
1 each

Multi tester 1

To measure resistance values
and voltages (AC/DC).
RS-232C cable 1

For writing DR data
USB memory or USB cable 1

For USB Updater.
IPS tool 1
See " 3.5.10 Service tool list
(p150)".
CAT 1
Intra-mart 1
RESCUE 1
USB firmware for updater 1
EasyMP Network firmware for
updater
1
Microsoft .Net Framework 3.5
or later
1
USB COM Driver 1
Tool Name Qt. Availability Application
Screwdriver magnetizer 1

To prevent the screw from
falling into the projector
Tool Name Qt. Availability Application

Epson EB-E10 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	0 - 1.76 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Screen size compatibility	22 - 350 \
Projection distance (wide)	0.87 - 10.34 m
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2200 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Focus	Manual
Throw ratio	1.44 - 1.95:1
Fixed focal length	16.7 mm
Full HD	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
AC (power) in	Yes
Composite video in	0
HDMI connector type	Full-size
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	2 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Housing material	Plastic
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Bundled software	Inhalt DIY-App, Epson Projektor Management, Epson Projektor Professional Tool
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
USB display function	2 in 1: Image / Mouse

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	376 mm
Package width	327 mm
Package height	152 mm
Package weight	3716 g
