Epson EB-E10 Service Manual

EB-E01 series INTERNAL USE ONLY
SEIKO EPSON 5 Revision A
SAFETY INSTRUCTIONS
The precautionary measures itemized below should be fully understood when
performing repair and maintenance procedures.
When disassembling/assembling, be sure to turn off the power
switch and pull out the power cable from the projector beforehand.
Be extremely careful about the current-carrying part during a test
operation, signal measurement or any other situations that is
necessary to perform the repair/maintenance work with the power
turned on and the cover removed.
Take off the things made of metal (such as a wrist watch, cuff
buttons, rings, tie pin, etc.) which may come in contact with the
parts inside the projector.
Do not touch the lamp assy. or the parts around it. They are
extremely hot even after completing the cooling down operation,
and may cause a burn injury. Therefore, leave the unit until it
becomes cool enough before performing maintenance work.
Never let the safety devices mounted in this product inactivated,
modify the safety devices or replace them with the ones that are not
designated for any reason whatsoever. (Such actions may endanger
the projector's safety operation and may result in a fire or serious
injury.)
Never modify the product for any reason whatsoever. (Except for a
case that is under the instructions to do so. In such a case,
understand the instructions thoroughly in advance and perform
modification appropriately.)
Never peer through the projection lens during repair/maintenance
work when the power is on. (Such an action may cause a visual
disability because of a very strong light emission.)
Never use a deformed plug or a damaged power cable to this
product. If any deformations or damages are found on the power
cable or plug section, replace it with a new specified power cable.
Never use the air blowers that contain flammable gas in repair/
maintenance work.
Never use or replace with any service parts that is not specified by
EPSON.
Do not disassemble any parts or components not specified in this
manual.
Do not apply any shock or vibration. (Otherwise, misalignment of
the optical parts inside the engine may cause irregular reflection of
the light and may result in burn (smoke) or damage to the internal
parts.)
Do not touch any parts such as inorganic polarizers that are
instructed not to.

Epson EB-E10 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	0 - 1.76 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Screen size compatibility	22 - 350 \
Projection distance (wide)	0.87 - 10.34 m
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2200 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Focus	Manual
Throw ratio	1.44 - 1.95:1
Fixed focal length	16.7 mm
Full HD	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
AC (power) in	Yes
Composite video in	0
HDMI connector type	Full-size
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	2 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Housing material	Plastic
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Bundled software	Inhalt DIY-App, Epson Projektor Management, Epson Projektor Professional Tool
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
USB display function	2 in 1: Image / Mouse

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	376 mm
Package width	327 mm
Package height	152 mm
Package weight	3716 g
