Epson Expression 10000XL User Manual

34 Getting the Most From Your Scanner
Using Unsharp Mask
If you have photographic images that look slightly fuzzy or indistinct, you can
sharpen them by turning on the Unsharp Mask adjustment in Office or Professional
Mode. (In Home Mode, this adjustment is automatically applied and you cannot
deselect it.)
1. Preview your image, then marquee-select the area you want to scan.
2. In Office Mode, select Unsharp Mask in the Image Adjustments section. In
Professional Mode, scroll down to the Adjustments section and then select
Unsharp Mask, as shown below:
3. In Professional Mode, click (Windows) or (Macintosh) and then choose a
Level to increase or decrease the effect.
Note: The Unsharp Mask Filter is not available if you’ve selected Color Smoothing,
Halftone, or Black & White as the Image Type.
Before After

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
