Epson Expression 10000XL User Manual

70 Solving Problems
Checking the Status Lights
You can diagnose some problems by checking the scanner’s lights, as described below.
If you don’t find the answer here, see “Problems and Solutions” on page 71.
Light Scanner Status
Ready light is on or
flashing.
The green Ready light is on when the scanner is ready to scan.
It flashes when scanning is in progress.
Error and Ready
lights are both off.
Make sure your scanner is connected to a working outlet, then
press the . power button.
Error and Ready
lights are both on.
The scanner has received an incorrect command from your
scanner software. Try scanning again. If the problem persists,
try reinstalling your scanner software (see page 77).
Error and Ready
lights are both
flashing.
If you’re using the automatic document feeder, there may be a
paper jam. Clear any jammed paper as described on page 61,
then close all open covers.
If this doesn’t solve the problem, there may be a problem with
the fluorescent lamp, or another problem. Contact Epson as
described on page 79.
Error light
Ready light
a Start button
. Power button

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
