Epson Expression 10000XL User Manual

46 Using Optional Equipment
Transparency Unit
The transparency unit (B12B813362) lets you scan transparent materials—35 mm
slides, filmstrips, and negatives, 4 × 5 inch film, medium format (120/220) film, and
nonstandard film sizes up to 12.2 × 16.5 inches (309 × 420 mm). To switch
from scanning transparent materials to ordinary paper documents, see page 54.
Note: The transparency unit is optional for the GA version of the Expression 10000XL. It
is included with the Photo version.
Unpacking the Transparency Unit
Make sure that all of the following items are included in the transparency unit box. If
any items are missing or damaged, contact your Epson dealer, or contact Epson at
(562) 276-4382 (in the United States) or (905) 709-3839 (in Canada). Keep all the
packing materials so you can use them for storage when you are not scanning
transparencies.
Transparency unit
(including reflective
document mat)
Film holders
(two of each type)
Transparency guide

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
