Epson Expression 10000XL User Manual

36 Getting the Most From Your Scanner
Using Backlight Correction
If you have photographic images that are too dark because of backlighting, you can
remove the shadows with Backlight Correction. This feature works in both Home and
Professional Mode, but Professional Mode lets you control the level of correction you
want to apply.
1. Preview your image, then marquee-select the area you want to scan.
2. In Home Mode, select Backlight Correction in the Image Adjustments section.
In Professional Mode, scroll down to the Adjustments section and then select
Backlight Correction, as shown below:
3. In Professional Mode, click (Windows) or (Macintosh), then choose a level
to increase or decrease the effect.
Before After

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
