Epson Expression 10000XL User Manual

40 Getting the Most From Your Scanner
Previewing Your Images in Thumbnail Mode
When scanning multiple images, you can use the Thumbnail preview screen to locate
each image automatically. (To select multiple images in the Full-size preview screen,
see page 18.) Follow these steps:
1. Start EPSON Scan and follow the instructions on page 23 (for photos) or on
page 51 (for film) to make the correct settings for your document.
Note: You can scan your images in either Home or Professional Mode, but
Professional Mode is recommended for greater control over the results.
2. Click the checkbox below the
Preview button to select
Thumbnail as the type of preview
screen you want to use.
3. Click the Preview button to view
previews of all your images.
You see this screen:
Select all
Erase marquee
Mirror image
Rotate image
Enlarge
preview

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
