Epson Expression 10000XL User Manual

Using Optional Equipment 59
Follow these steps to load a document:
1. Arrange the pages of your document into a stack. If necessary, slide the edge guide
out of the way, then place the stack face-up on the ADF’s input tray. Insert it
short end first until it meets resistance. Do not force it into the ADF.
2. Slide the edge guide flush against the stack, but not too tightly. If your pages are
long, you may need to extend the paper support.
3. Scan your document as described in the next section.
Note: Pages are fed from the top and ejected face-down, keeping them in their
original order.
Insert left
edge first
A
Landscape
Insert bottom
edge first
A
Portrait
Extend paper support
for long pages

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
