2. Remove the paper guide by moving it to the upright position
and pulling it straight up. Lift the printer cover by its back
edge and then pull it straight up and off the printer.
3. Holding the cut-sheet feeder in both hands, press down on
the latch levers and fit the notches over the printer’s mounting
posts, as shown below. Release the latch levers to lock the
feeder in place. If you are installing the high-capacity or
double-bin cut-sheet feeder, see the following illustration.
