14. Replace the printer cover by inserting the front tabs into the
slots on the printer and lowering the cover into place. Then
push it down until it clicks.
Cut-Sheet Feeder
Two types of optional cut-sheet feeders are available for use with
your printer as shown below:
You can use either one of these separately, or you can use both
feeders together as a double-bin cut-sheet feeder to automatically
load two different types of single-sheet paper.
The single-bin cut-sheet feeder holds up to 50 single sheets. The
high-capacity cut-sheet feeder holds up to 150 single sheets or up
to 25 envelopes.
the single-bin cut-sheet feeder: FX-890:C80637✽
FX-2190:C80369✽
the high-capacity cut-sheet feeder: FX-890:C80638✽
FX-2190:C80640✽
