Installation 3. Power-ON
RC700 Series Rev.3 57
N2, N6
(Figure: The external short connector is connected N2)
For details on the brake release unit and the Manipulators, refer to Manipulator manual.
WARNING
If the Manipulator is operated without connecting the above parts,
the brakes cannot be released and it may cause damage on them.
After using the brake release unit, be sure to connect the
external
short connector to the Manipulator, or check connection of the
connector for the brake release unit.
WARNING
When connecting or replacing the parts, turn OFF the power to the
Controller and the brake release unit. Inserting and removing the
connector
while the power is ON may result in electrical shock.
