Epson SC-S30600 Series - Tube Inner Cleaning

SC-S30600 Series Revision B
ADJUSTMENT Ink Supply Related Checks and Adjustments 258
Confidential
4.12.2 Tube Inner Cleaning
THINGS TO PREPARE
Cleaning Cartridge
EXECUTION MODE
Normal Mode
PROCEDURE
1. Turn the printer ON.
2. Start the Service Program and select Tube inner cleaning.
3. Click [Run]. An explanatory dialog box is displayed.
4. Clean the tubes following the on-screen instructions.
5. When the cleaning is finished, click [Finish].
6. Turn the printer OFF and finish the adjustment.
Figure 4-49. [Tube inner cleaning] Screen
