Epson SC-S30600 Series User Manual

SC-S30600 Series Revision B
APPENDIX Part names used in this manual 310
Confidential
6.4 Part names used in this manual
To make it easier to locate the target part from its part name, this manual uses the part
names different from the ASP part names. The table below shows the conversion of the
part names used in this manual and the corresponding ASP part names.
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3 sec.No.)
Housing
Panel Unit PANEL ASSY ESL;ASP 3.4.3.1
Right Upper Cover
 COVER,TOP,RIGHT,ASSY;
ASP
 COVER,MAINTENANCE
 COVER,MAINTENANCE,R
IGHT,ASSY;ASP
3.4.3.2
Right Front Cover
 COVER,FRONT,RIGHT,64,
ASSY;ASP
 COVER,IH
3.4.3.3
Right Cover
COVER SIDE RIGHT DOWN
ASSY ESL;ASP
3.4.3.4
Right Lower Cover
HOUSING,BASE,SUPPORT,
RIGHT
3.4.3.5
Left Rear Cover CAP,COVER,TUBE 3.4.3.6
Left Upper Cover
 COVER,TOP,LEFT,ASSY;
ASP
 COVER,MAINTENANCE,
HEAD
 COVER,MAINTENANCE,L
EFT,ASSY;ASP
3.4.3.7
Left Front Cover
COVER FRONT LEFT ASSY
ESL ASP
3.4.3.8
L Maintenance Cover Sensor
FULL,MAINTENANCE
OPEN ASSY ESL;ASP
3.4.3.8
Left Cover
COVER SIDE LEFT DOWN
ASSY ESL;ASP
3.4.3.9
Left Lower Cover
HOUSING,BASE,SUPPORT,L
EFT
3.4.3.10
Upper Cover N/A 3.4.3.11
Board Box Cover N/A 3.4.3.12
R Maintenance Cover Sensor
INK LOCK,MAINTENANCE,
HOME,ASSY ESL;ASP
3.4.3.13
Housing
Front Cover R Sensor
INK LOCK,P COVER,
HOME,ASSY ESL;ASP
3.4.3.14
Front Cover L Sensor
PRINTER,COVER,OPEN
ASSY ESL;ASP
3.4.3.15
Electric Circuit
Components
Main Board BOARD ASSY.,MAIN 3.4.4.1
Main-B Board BOARD ASSY.,MAIN 3.4.4.2
Power Supply Board
BOARD ASSY.,POWER
SUPPLY
3.4.4.3
Sub Board BOARD ASSY.,SUB 3.4.4.4
Sub-D Board BOARD ASSY.,SUB 3.4.4.5
Sub-E Board BOARD ASSY.,SUB 3.4.4.6
Sub-M Board BOARD ASSY.,SUB 3.4.4.7
Box Cooling Fan FAN SET.DC;ASP 3.4.4.8
Carriage Mechanism/
Ink System
Mechanism
CR Cover COVER,CR 3.4.5.1
Damper Kit DUCT,CR.,ASSY ESL;ASP 3.4.5.2
Print Head PRINT HEAD,IA522V 3.4.5.3
Head FFC HARNESS,HEAD ASSY;ASP 3.4.5.4
Head Relay FFC
HARNESS,HEAD
ASSY,C;ASP
3.4.5.5
CR FFC HARNESS,CR 3.4.5.6
CR Scale SCALE,CR;ASP 3.4.5.7
CR Timing Belt BELT,CR 3.4.5.8
CR Motor MOTOR ASSY.,CR 3.4.5.9
CR HP Sensor DETECTOR,RPI-2500 3.4.5.10
CR Encoder BOARD ASSY.,ENCODER 3.4.5.11
APG Unit MOTOR ASSY.,ASF,SUB 3.4.5.12
PG Sensor DETECTOR,RPI-2500 3.4.5.13
Pump Cap Unit PUMP,CAP.,ASSY ESL;ASP 3.4.5.14
IC Holder HOLDER,IC.,ASSY ESL;ASP 3.4.5.15
Ink Tube
TUBE,INK SUPPLY.,ASSY
ESL;ASP
3.4.5.16
Flushing Box FLASHING BOX ASSY;ASP 3.4.5.17
CR Unit CARRIAGE ASSY ESL;ASP 3.4.5.18
Oil Pad Holder OIL PAD,ASSY ESL;ASP 3.4.5.19
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3 sec.No.)
