Epson SC-S30600 Series User Manual

SC-S30600 Series Revision B
APPENDIX Part names used in this manual 311
Confidential
Carriage Mechanism/
Ink System
Mechanism
PW Sensor
BOARD
ASSY.,DETECTOR,PW;B
3.4.5.20
IM Sensor BOARD ASSY.,INK MARK 3.4.5.21
Paper Feed
Mechanism
Media Loading Lever KNOB,LEVER 3.4.6.1
Media Loading Lever Sensor DETECTOR,RPI-2500 3.4.6.2
PF Motor MOTOR ASSY.,PF;ASP 3.4.6.3
PF Encoder
BOARD
ASSY.,ENCODER,PF
3.4.6.4
PF Scale SCALE,PF ASSY;ASP 3.4.6.5
PF Timing Belt TIMING BELT,PF 3.4.6.6
Driven Roller Assy
ROLLER
ASSY.,DRIVEN;ASP
3.4.6.7
Suction Fan FAN ASSY.,ABSORPTION 3.4.6.8
PE Sensor
BOARD
ASSY.,DETECTOR,PW;B
3.4.6.9
Heater Mechanism
Pre Heater
PRE,HEATER,ASSY
ESL;ASP
3.4.7.1
Platen Heater
HEATER,PAPER
GUIDE,FRONT;ASP
3.4.7.2
After Heater
AFTER,HEATER,ASSY
ESL;ASP
3.4.7.3
Cooling Fan
FAN SET. DC (PROPELLER
TYPE)
3.4.7.4
Roll Unit
Roll Unit N/A 3.4.8.1
Roll Receiver Assy
GUIDE,ROLL PAPER,JACK
ASSY ASP
3.4.8.2
Roll Paper Holder
HOLDER,ROLL PAPER
ASSY ASP
3.4.8.3
Sub-F Board (Roll) BOARD ASSY.,SUB 3.4.8.4
ATC Motor MOTOR,ASSY.,REWIND 3.4.8.5
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3 sec.No.)
Reel Unit
Reel Unit N/A 3.4.9.1
Roll Paper Holder
HOLDER,ROLL PAPER
ASSY ASP
3.4.9.2
Sub-F Board (Reel) BOARD ASSY.,SUB 3.4.9.3
Reel Motor MOTOR,ASSY.,REWIND 3.4.9.4
Tension Bar Upper Sensor DETECTOR,RPI-2500 3.4.9.5
Tension Bar Lower Sensor DETECTOR,RPI-2500 3.4.9.5
Additional Drying
Fan Unit
Drying Fan Unit N/A 3.4.10.1
Drying Fan Cover N/A 3.4.10.2
Sub-I Board BOARD ASSY.,SUB 3.4.10.3
Drying Fan Power Supply
Board
BOARD ASSY.,POWER
SUPPLY
3.4.10.4
Drying Fan FAN ASSY.,DRYING 3.4.10.5
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3 sec.No.)
