SC-S30600 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 177
Confidential
3.4.8.2 Roll Receiver Assy
1. Lift the Roll Receiver Assy to disengage the two hooks, and remove the Roll
Receiver Assy.
Figure 3-141. Removing the Roll Receiver Assy
Hooks
Roll Receiver Assy
- Rear side -
