DISASSEMBLY & ASSEMBLY Overview 65
Confidential
3.1.4 Recommended Tools
To protect this product from damage, use the tools indicated in the following table.
For the tools required to perform the adjustment, refer to “Tools/Consumables for
Adjustments” in Chapter 4.
?
Table 3-1. Tools
Name Description Target Part
Phillips screwdriver, No. 1
4 cm or longer shaft length (The
one with a magnet is
recommended)
 Print Head
 Some encoders/sensors
Phillips screwdriver, No. 2
25 cm or longer shaft length (The
one with a magnet is
recommended)
Parts in general
Stubby driver with 4 cm or shorter
shaft length (The one with a
magnet is recommended)
 APG Unit
 Platen Heater
Tweezers Nothing in particular Parts in general
C-ring pliers To remove C-rings (. Roll Paper Holder
Acetate tape
To secure the cable/harness, or for
the protection against the sharp
edge
Parts in general (Use this tape
when it is removed or when
replacing the part)
Waste cloth
To prevent staining the printer
with ink during operation
 Ink Tube
 IC Holder
 Flushing Box
 Damper Kit
 Print Head
 Pump Cap Unit
