SC-S30600 Series Revision B
APPENDIX Connection Diagram 295
Confidential
6.2.3 Ink Cartridge Holder
Main Board
CSIC Contact Module
1
2
Cable No. Connection
1
CSIC Contact CSIC Contact Module
2
CSIC Contact Module Main Board (CN215)
