Epson SC-S30600 Series User Manual

SC-S30600 Series Revision B
APPENDIX Connection Diagram 293
Confidential
Cable No. Connection
1
Front Cover L Sensor Main Board (CN18)
2
L Maintenance Cover Sensor Main Board (CN19)
3
Suction Fan Main Board (CN31)
4
Suction Fan Main Board (CN32)
5
Front Cover R Sensor Main Board (CN271)
6
R Maintenance Cover Sensor Main Board (CN272)
7
PE Sensor Main Board (CN293)
8
CR HP Sensor/Media Loading Lever
Sensor
Main Board (CN250)
9
Panel Board (CN1) Main Board (CN13)
