EPSON Stylus CX4100/CX4200/CX4700/CX4800/DX4200/DX4800/DX4850 Revision A
ADJUSTMENT Overview 172
5.1 Overview
This section describes the procedure for adjustments required when the printer is
disassembled and assembled for repair or service.
5.1.1 Required Adjustments
If you remove or replace the specific part in your service/repair, you have to perform
the appropriate adjustment as listed Table 5-1 below.
In this printer, it is necessary to perform appropriate adjustment in order to maintain
consistent printing function and quality, eliminate differences of each printer
mechanism’s characteristics. Therefore, in case that the combination between the
printer mechanism and the Main Board changes or the Print Head is replaced during
the repair service, you must input the correct adjustment value into the EEPROM on
the Main Board by using the Adjustment program.
Table 5-1. Required Adjustments
C H E C K
P O I N T
In case that any parts are removed and assembled on the repair
product while running the Adjustment program, make sure to
turn off the printer.
EEPROM data copy
Market setting
USB ID input
Waste ink pad counter
Ink charge
Head ID input
Top margin adjustment
First dot adjustment
PW sensor adjustment
Head angular adjustment
Bi-d adjustment
PF deterioration adjustment
*1
CR offset
PF adjustment
PF band adjustment
ASF unit
removal --- --- --- --- --- --- O O O --- --- O --- O O
replacement --- --- --- --- --- --- O O O --- --- O --- O O
CR motor
removal --- --- --- --- --- --- --- O O --- O --- --- --- ---
replacement --- --- --- --- --- --- --- O O --- O --- O --- ---
Paper guide upper
removal --- --- --- --- --- --- O --- --- --- --- O --- O O
replacement --- --- --- --- --- --- O --- --- --- --- O --- O O
Front frame
removal --- --- --- --- --- --- --- O --- O O --- --- --- ---
replacement --- --- --- --- --- --- --- O --- O O --- --- --- ---
Print head
removal --- --- --- --- --- --- O O O O O O --- O O
replacement --- --- --- --- O O O O O O O O --- O O
Adjustment item
Replaced part
