PRODUCT DESCRIPTION Control Panel 54
1.6.4 Printer Condition and Panel Status
Note : “---”: No change
Blink: 0.5sec. On + 0.5sec. Off repetition
Blink 2: 0.2sec. On + 0.2sec. Off + 0.2sec. On + 0.4sec. Off repetition
Blink 3: Blink on and off along with access to a memory card
Reverse blink:0.5sec. Off + 0.5sec. On repetition (opposite of “Blink”)
Fast blink: 0.2sec. On + 0.2sec. Off repetition
Slow blink: 2.0sec. On + 2.0sec. Off repetition
Note *1: When the setting is “On”.
*2: After finishing copying, the counter returns to the preset number of copies.
Table 1-52. Printer Condition and Panel Status
Printer
status
Indicators
Priority
Power LED Error LED Ink LED
Memory Card LED
7-seg.
LED
Paper Type LED Paper Size LED
Fit to Page
LED
Card Access
LED
1 2 3 1 2 1 2
3
Power on
(Normal ready mode)
On — — — — — — — — — — — — — 24
Card printing mode (Print
All/DPOF)
— — — — — On Off Selected type is On Selected size is On Off —
23
Card printing mode
(Index Sheet scanning &
printing)
— — — — On — Off Selected type is On Selected size is On Off —
Card printing mode (Print
index sheet)
— — — On — — Off On — On — — Off —
Copying mode — — — Off Off Off
Displays copy
numbers.
Displays “-” for
continuous
copy of 20
pages or more.
Selected type is On Selected size is On
On (if the
setting is on)
—
DSC direct mode — — — — — On “P” blink Selected type is On Selected size is On Off —
Ink low — — Blink — — — — — — — — — — — 22
