EPSON Stylus CX4100/CX4200/CX4700/CX4800/DX4200/DX4800/DX4850 Revision A
APPENDIX Parts List 212
7.3 Parts List
Parts list for EPSON Stylus CX4700/CX4800/DX4800/DX4850
Code Parts Name
100 COVER,ASF
101 COVER,REAR;EDG2
102 COVER,USB;EDG2
103 HOUSING,CARD SLOT;EDG2
104 COVER,CARD SLOT;B;EFS
105 PAPER SUPPORT ASSY.
106 HOUSING,UPPER,EDG2
108 STACKER ASSY.;EDG2
110 COMPRESSION SPRING,5.1
111 FOOT
112 LOCK,STACKER
113 HOUSING,LOWER,EDG2
115 BUTTON,INK;B
116 BUTTON,COPY;B;EGM
117 BUTTON,POWER;B;EBM
118 BUTTON,S
119 BUTTON,STOP
120 SPRING,COVER,CARD SLOT;B
121 DECORATION PLATE,H.PANEL;B;ENM3;TEXT;LTR
122 HOUSING,PANEL;C
123 OPTICAL TUBE,PANEL,UPPER
124 COVER,LED
125 OPTICAL TUBE,PANEL,LOWER
450 BOARD ASSY.,PANEL
809 HINGE,ASSY.
811 HINGE,L
812 COVER,DOCUMENT ASSY.,CX4800
813 SCANNER ASSY.;EDG2
NON FIG LABEL,INK,POSITION
200 MAIN BOARD ASSY.
300 POWER SUPPLY UNIT;100V
500 PRINTER MECHANISM(ASP)MAO10-101
501 FRAME,FRONT;B
502 COVER,CABLE,HEAD
503 COVER,CARTRIDGE;EPG2
504 FRAME,HOLDER,FFC
505 SCALE,PF;B
506 POROUS PAD,CAP,LOWER
508 GUIDE,FFC
510 ASF UNIT;B
512 CONNECTER,CSIC
513 BOARD ASSY.,CSIC
514 GROUNDING SPRING,PF
515 FRAME,GUIDE,CR
516 LEVER,PARALLEL ADJUSTMENT,RIGHT
517 LEVER,PARALLEL ADJUSTMENT,LEFT
518 TORSION SPRING,SHAFT,CR,GUIDE
519 PRESSING SPRING,SHAFT,CR,GUIDE
520 SCALE,CR
521 EXTENSION SPRING,3.289
522 PAPER GUIDE,FRONT,SUPPORT
523 INK SYSTEM ASSY.
524 MOTOR,ASSY.,PF
525 ROLLER,PF ASSY.
527 PAPER GUIDE,FRONT ASSY.
Code Parts Name
