Epson Stylus DX4850 Service Manual

EPSON Stylus CX4100/CX4200/CX4700/CX4800/DX4200/DX4800/DX4850 Revision A
APPENDIX Parts List 213
528 HOLDER,SHAFT ASSY.
529 TORSION SPRING,0.22
530 BOARD ASSY.,DETECTOR
531 CR SUB ASSY.
532 CABLE,HEAD
533 BOARD ASSY.,ENCODER
534 BOARD ASSY.,DETECTOR,PW
535 MOTOR ASSY.,CR
536 DETECTOR ASSY.,PG
537 PRINT HEAD
538 CLAMP,TUBE
539 LEVER,PG;EPG2
540 POROUS PAD,JOINT,LOWER
541 TUBE,INK EJECT
542 JOINT,INK EJECT;B
543 MOUNTING PLATE,LEVER,PG
554 COMPRESSION SPRING,2.51
555 EXTENSION SPRING,0.143
556 TORSION SPRING,6.45
557 SHAFT,CR GUIDE
561 POROUS PAD,INK EJECT,7;B
562 POROUS PAD,INK EJECT,8;B
563 POROUS PAD,INK EJECT,6;B
564 POROUS PAD,INK EJECT,5;B
565 POROUS PAD,INK EJECT,3;B
566 DIFFUSION SHEET,INK EJECT,ASP
567 POROUS PAD,INK EJECT,4;B
NON FIG PLANE WASHER,2.6X0.5X8
NON FIG COMPRESSION SPRING,5.1
Code Parts Name
NON FIG SPACER,4.1X0.5,L/NA
NON FIG TORSION SPRING,LEVER,CARTRIDGE;B
NON FIG SPUR GEAR,30.8
NON FIG INK CART.UNBOXED,BK-S,PIG'T;G38C,WST,AS
NON FIG INK CART.UNBOXED,C-S,PIG'T;G38C,WST,AS
NON FIG INK CART.UNBOXED,M-S,PIG'T;G38C,WST,AS
NON FIG INK CART.UNBOXED,Y-S,PIG'T;G38C,WST,AS
