EPSON Stylus CX4100/CX4200/CX4700/CX4800/DX4200/DX4800/DX4850 Revision A
APPENDIX Parts List 214
Parts list for EPSON Stylus CX4100/CX4200/DX4200
Code Parts Name
100 COVER,ASF
101 COVER,REAR;EDG2
102 COVER,USB;EDG2
105 PAPER SUPPORT ASSY.
106 HOUSING,UPPER,EDG2
108 STACKER ASSY.;EDG2
111 FOOT
112 LOCK,STACKER
113 HOUSING,LOWER,EDG2
115 BUTTON,INK;B;ENB7
116 BUTTON,COPY;B;ENB7
117 BUTTON,POWER;B;ENB7
118 BUTTON,S;ENB7
119 BUTTON,STOP;ENB7
121 DECORATION PLATE,H.PANEL;EBM;TEXT;LTR
122 HOUSING,PANEL;C
124 COVER,LED
125 OPTICAL TUBE,PANEL,LOWER
450 BOARD ASSY.,PANEL
809 HINGE,ASSY.
811 HINGE,L
812 SCANNER ASSY.;EDG2
813 COVER,DOCUMENT ASSY.,CX4100
NON FIG LABEL,INK,POSITION
200 MAIN BOARD ASSY.
300 POWER SUPPLY UNIT;100V
500 PRINTER MECHANISM(ASP)MAO10-102
501 FRAME,FRONT;B
502 COVER,CABLE,HEAD
503 COVER,CARTRIDGE;EPG2
504 FRAME,HOLDER,FFC
505 SCALE,PF;B
506 POROUS PAD,CAP,LOWER
508 GUIDE,FFC
510 ASF UNIT;B
512 CONNECTER,CSIC
513 BOARD ASSY.,CSIC
514 GROUNDING SPRING,PF
515 FRAME,GUIDE,CR
516 LEVER,PARALLEL ADJUSTMENT,RIGHT
517 LEVER,PARALLEL ADJUSTMENT,LEFT
518 TORSION SPRING,SHAFT,CR,GUIDE
519 PRESSING SPRING,SHAFT,CR,GUIDE
520 SCALE,CR
521 EXTENSION SPRING,3.289
522 PAPER GUIDE,FRONT,SUPPORT
523 INK SYSTEM ASSY.
524 MOTOR,ASSY.,PF
525 ROLLER,PF ASSY.
526 PAPER GUIDE,UPPER ASSY.
527 PAPER GUIDE,FRONT ASSY.
528 HOLDER,SHAFT ASSY.
529 TORSION SPRING,0.22
530 BOARD ASSY.,DETECTOR
531 CR SUB ASSY.
532 CABLE,HEAD
533 BOARD ASSY.,ENCODER
Code Parts Name
