Epson Stylus DX4850 Service Manual

EPSON Stylus CX4100/CX4200/CX4700/CX4800/DX4200/DX4800/DX4850 Revision A
APPENDIX Parts List 215
534 BOARD ASSY.,DETECTOR,PW
535 MOTOR ASSY.,CR
536 DETECTOR ASSY.,PG
537 PRINT HEAD
538 CLAMP,TUBE
539 LEVER,PG;EPG2
540 POROUS PAD,JOINT,LOWER
541 TUBE,INK EJECT
542 JOINT,INK EJECT;B
543 MOUNTING PLATE,LEVER,PG
554 COMPRESSION SPRING,2.51
555 EXTENSION SPRING,0.143
556 TORSION SPRING,6.45
557 SHAFT,CR GUIDE
561 POROUS PAD,INK EJECT,7;B
562 POROUS PAD,INK EJECT,8;B
563 POROUS PAD,INK EJECT,6;B
564 POROUS PAD,INK EJECT,5;B
565 POROUS PAD,INK EJECT,3;B
566 DIFFUSION SHEET,INK EJECT,ASP
567 POROUS PAD,INK EJECT,4;B
NON FIG PLANE WASHER,2.6X0.5X8
NON FIG COMPRESSION SPRING,5.1
NON FIG SPACER,4.1X0.5,L/NA
NON FIG TORSION SPRING,LEVER,CARTRIDGE;B
NON FIG SPUR GEAR,30.8
NON FIG COVER,INK EJECT
NON FIG INK CART.UNBOXED,BK-S,PIG'T;G38C,WST,AS
Code Parts Name
NON FIG INK CART.UNBOXED,C-S,PIG'T;G38C,WST,AS
NON FIG INK CART.UNBOXED,M-S,PIG'T;G38C,WST,AS
NON FIG INK CART.UNBOXED,Y-S,PIG'T;G38C,WST,AS
