EPSON Stylus CX4100/CX4200/CX4700/CX4800/DX4200/DX4800/DX4850 Revision A
ADJUSTMENT Overview 174
Note *1: There are two kinds of adjustment to the PF deterioration adjustment:
“initialize PF deterioration offset” and “disenable PF deterioration offset”.
*2: If the printer you make repairs on is equipped with an ASF frame for Stylus
CX4700/CX4800/DX4800/DX4850, following values should be
entered in advance:
Address 5A<H> Data 39 <H>
If the printer is equipped with an ASF frame for Stylus CX4500/CX4600 (first mass
production of IEI Stylus CX4700/CX4800/DX4800/DX4850), these values need not
to be entered.
CR unit
removal --- --- --- --- --- --- O O O O O --- --- O O
replacement --- --- --- --- --- --- O O O O O --- O O O
CR guide shaft
removal --- --- --- --- --- --- O O --- O --- --- --- ---
replacement --- --- --- --- --- --- --- O O --- O --- O --- ---
Star wheel assy.
removal --- --- --- --- --- --- --- --- --- --- --- O --- O O
replacement --- --- --- --- --- --- --- --- --- --- --- O --- O O
PF roller assy
removal --- --- --- --- --- --- O --- O --- --- O --- O O
replacement --- --- --- --- --- --- O --- O --- --- O --- O O
EEPROM data copy
Market setting
USB ID input
Waste ink pad counter
Ink charge
Head ID input
Top margin adjustment
First dot adjustment
PW sensor adjustment
Head angular adjustment
Bi-d adjustment
PF deterioration adjustment
*1
CR offset
PF adjustment
PF band adjustment
C A U T I O N
When the Main board is replaced with a new one, you may have
to replace waste drain ink pad also in case the EEPROM
parameter back up function is not available on the defective
main board.
After completing the adjustment, check the printing result with
A4 check pattern by using the Adjustment program.
If the result is not good, perform appropriate adjustment.
If using new main board in the printer mechanism replacement,
you need to perform EEPROM initial setting of main board.
And then, please perform the adjustment by usual procedure.
Adjustment item
Replaced part
To Next Page
