EPSON Stylus CX4100/CX4200/CX4700/CX4800/DX4200/DX4800/DX4850 Revision A
ADJUSTMENT Adjustment Except Adjustment Program 185
5. Click the “Single Test” icon on the “EPSON Scanner Function Test -
C592B00W” window.
Figure 5-19. Original Adjustment (3)
6. Enter the product number on the “Single Test” window, select “Write Zero
Correction Value”, and press the [Execute] button.
Figure 5-20. Original Adjustment (4)
7. A progress bar will be displayed followed by the window described below.
<Window displayed when the adjustment is completed successfully>
Figure 5-21. Window displayed when the adjustment is completed successfully (1)
Figure 5-22. Window displayed when the adjustment is completed successfully (2)
Single Test Icon
Enter the last five digits of the scanner production
control number label, put one space, and then enter the
last five digits of the printer production control number.
Execute Button
Write Zero Correction Value
To Next Page
