Page #200 background imageLoading...
Page #200 background image
EPSON Stylus CX4100/CX4200/CX4700/CX4800/DX4200/DX4800/DX4850 Revision A
APPENDIX Connector Summary 200
31 FWPB Write protect signal
32 Reserve Not connected
33 FRDY Ready
34 SCLK Stick inserted/removed detect terminal
35 FWEB Write enable signal
36 VCC Power supply for SmartMedia
37 FOEB Output enable signal
38 GND Ground
39 FALE Address latch enable signal
40 VDD Power supply for SD Memory Card
41 FCEB Chip enable signal
42 Ground
43 FCLE Command latch enable signal
44 CMD Command/Response
45 VCC Power supply for SmartMedia
46 CD/DAT3 Card Detect /Data Line (Bit 3)
47 GND Ground
48 DAT2 Data Line (Bit 2)
49 WP1 Write protect seal condition
Table 7-16. CN16-USB Host I/F Board
Pin Signal Name I/O Function
1 VBUS_IN USB VBUS Input
2 D- Bi-D USB D- Signal
3 D+ Bi-D USB D+ Signal
4 GND Ground
Table 7-15. CN15 - Memory Card
Pin Signal Name I/O Function
