EPSON Stylus Pro 7400/7800/9400/9800 Revision B
Adjustment Check Results 366
5.5.5 Print Image
Procedure
1. Turn the printer ON.
2. Click the [Open] button and select any one of the image files (bmp) in the
“tanzaku” folder in the “adjwiz2” folder in which the Adjustment Program is
stored.
3. Select media type from the [Media Type] pull-down menu.
4. Click the [Print] button to print the selected image.
5. After checking the printed image, click the [Finish] button.
Figure 5-103. [Print Image] Screen
C A U T I O N
Before performing the following operations, be sure to select a
paper size to print the image.
To Next Page
