EPSON Stylus CX7300/CX7400/DX7400/NX200/TX200 series/SX200 series/Stylus CX8300/CX8400/DX8400/NX400/TX400 series/SX400 series Revision C
ADJUSTMENT Adjustment Items and Overview 143
Confidential
PF motor heat
protection control
This must be carried out for efficient heat control of the PF motor. Electrical
variation of the motor and the power supply board are measured to acquire
correction values for them.
Select the parts that you replaced. The correction values are
automatically written to the main board.
• Adjustment Program
PF adjustment
This corrects variations in paper feed accuracy when using the Microweave
to achieve higher print quality.
A PF adjustment pattern is printed. Examine the printout patterns and
enter the value for the best pattern to register the correction value to
the printer.
(Carry out the procedure for each color.)
• Adjustment Program
PF band adjustment
This corrects variations in paper feed accuracy in the band print mode to
achieve higher print quality.
A PF band adjustment pattern is printed. Examine the printout
patterns and enter the value for the best pattern to register the
correction value to the printer.
• Adjustment Program
Bottom margin
adjustment
In order to improve the throughput, the printer minimizes the number of
print passes when printing on the bottom margin (bleed) in the borderless
printing. This may cause white area to appear on the bottom edge of the
borderless printout. In such case, use this adjustment to correct the printing
range on the bottom margin (bleed).
A bottom margin adjustment pattern is printed. Examine the printout
patterns and enter the value for best pattern to register the correction
value to the printer.
• Adjustment Program
•Ruler
Table 5-1. Adjustment Items
Adjustment Item Purpose Method Outline Tool
Table 5-2. Maintenance Items
Maintenance Item Purpose Method Outline Tool
Waste ink pad counter
The printer causes a maintenance error when the waste ink pad counter
reaches its maximum. Use this to reset the counter after replacing the
Waste Ink Pad. If you find the counter is close to the maximum during
servicing, carry out the pad replacement and the counter reset to avoid
the printer returned from the user due to the maintenance error.
After replacing the Waste Ink Pad, reset the counter to its default.
• Adjustment Program
Ink charge
This must be carried out after replacing the Printhead in order to fill ink
inside the new Printhead. The Printhead becomes ready for print.
Filling ink inside the Printhead is automatically performed. Print a
nozzle check pattern to check if all nozzles are firing ink properly.
• Adjustment Program
Table 5-3. Additional Functions
Additional Functions Purpose Method Outline Tool
Final check pattern
print
A4 size Use this to check if the all adjustments have been
properly made.
The all adjustment patterns are printed automatically.
• Adjustment Program
US Letter size
EEPROM dump
Use this to readout the EEPROM data for analysis.
The all EEPROM data is automatically readout and stored as a file.
• Adjustment Program
Printer information
check
Manual CL counter Use this to readout information on the printer
operations.
The printer information is automatically readout.
• Adjustment Program
I/C exchange CL counter
Timer CL counter
Print path counter
To Next Page
