EPSON Stylus CX7300/CX7400/DX7400/NX200/TX200 series/SX200 series/Stylus CX8300/CX8400/DX8400/NX400/TX400 series/SX400 series Revision C
PRODUCT DESCRIPTION Features 9
Confidential
1.1 Features
EPSON Stylus CX7300/TX200/CX8300/TX400 series are color ink-jet printers with
scanner function and have the following features.
The difference in appearance between the two models is LCD; CX8300/TX400 series
is equipped with LCD, and CX7300/TX200 series is not equipped with it.
Available Functions
Printer
Printing from a computer or directly printing from a memory card.
Scanner
Scanning from a computer
Copy
Stand alone copy using the scanning and printing functions
Memory card slot
Available as USB memory card slot for PC
Color LCD (CX8300/TX400 series only)
• 2.5-inch color TFD LCD (CX8300 series)
• 2.5-inch color α-TFT LCD (TX400 series)
High speed & High quality
Maximum print resolution: SMGA 5760 (H) x 1440 (V) dpi
D4-chips Turbo II Printhead achieves higher print speed than ever.
(Black: 90 nozzles x 1, Color: 90 nozzles x 1 per color)
Four independent ink cartridges is installed.
Newly developed pigment ink is employed.
Borderless printing on specified EPSON brand paper is available.
Dimensions
Stylus CX7300/CX8300 series
• Dimensions*
1
: 450 mm (W) x 340 mm (D) x 179 mm (H)
• Weight*
2
: CX8300 series: 5.9 kg
CX7300 series: 5.8 kg
Stylus TX200/TX400 series
• Dimensions*
1
: 450 mm (W) x 342 mm (D) x 182 mm (H)
• Weight*
2
: TX400 series: 5.9 kg
TX200 series: 5.8 kg
*1 :Paper support and stacker are closed. Rubber feet are excluded.
*2 :Excluding the weight of ink cartridges and power cable.
Figure 1-1. External View
Notation Product name
CX7300 series Stylus CX7300/CX7400/DX7400
TX200 series Stylus NX200/TX200/TX203/TX209/SX200/SX205
CX8300 series Stylus CX8300/CX8400/DX8400
TX400 series Stylus NX400/TX400/TX405/TX409/SX400/SX405
