EPSON Stylus CX7300/CX7400/DX7400/NX200/TX200 series/SX200 series/Stylus CX8300/CX8400/DX8400/NX400/TX400 series/SX400 series Revision C
DISASSEMBLY/ASSEMBLY Overview 94
Confidential
4.1.4 Procedural Differences between the Models
Some parts that are installed to CX7300/TX200 series and CX8300/TX400 series differ from each other because of the difference in the Panel Unit. The explanations in this chapter
are based on CX8300/TX400 series. When reassembling the CX7300/TX200 series, refer to the table below to make sure the differences between the models.
Table 4-3. Differences between Models
Item Description CX8300/TX400 series CX7300/TX200 series Reference
Panel Unit
You need to follow different steps to
remove the Panel Unit.
CX8300/TX400 series
Panel Unit/LCD Unit (p103)
CX7300/TX200 series
Panel Unit (CX7300/TX200 series)
(p139)
