EPSON Stylus CX7300/CX7400/DX7400/NX200/TX200 series/SX200 series/Stylus CX8300/CX8400/DX8400/NX400/TX400 series/SX400 series Revision C
DISASSEMBLY/ASSEMBLY Overview 91
Confidential
4.1 Overview
This section describes procedures for disassembling the main components of EPSON
Stylus CX7300/TX200/CX8300/TX400 series. Unless otherwise specified,
disassembled units or components can be reassembled by reversing the disassembly
procedure. Procedures which, if not strictly observed, could result in personal injury
are described under the heading “WARNING”. “CAUTION” signals a precaution
which, if ignored, could result in damage to equipment. Important tips for procedures
are described under the heading “CHECK POINT”. If the assembly procedure is
different from the reversed disassembly procedure, the correct procedure is described
under the heading “REASSEMBLY”. Any adjustments required after reassembly of
components or parts are described under the heading “ADJUSTMENT REQUIRED”.
When you have to remove any components or parts that are not described in this
chapter, refer to the exploded diagrams in the appendix.
Read the following precautions before disassembling and assembling.
4.1.1 Precautions
See the precautions given under the heading “WARNING” and “CAUTION” in the
following columns when disassembling or assembling EPSON Stylus CX7300/TX200/
CX8300/TX400 series.
In this chapter, the product names are called as follows:
Notation Product name
CX7300 series Stylus CX7300/CX7400/DX7400
TX200 series Stylus NX200/TX200/TX203/TX209/SX200/SX205
CX8300 series Stylus CX8300/CX8400/DX8400
TX400 series Stylus NX400/TX400/TX405/TX409/SX400/SX405
Disconnect the power cable before disassembling or
assembling the printer.
If you need to work on the printer with power applied, strictly
follow the instructions in this manual.
Always wear gloves for disassembly and reassembly to protect
your eyes from ink. If any ink gets in your eyes, wash your
eyes with clean water and consult a doctor immediately.
Always wear gloves for disassembly and reassembly to avoid
injury from sharp metal edges.
To protect sensitive microprocessors and circuitry, use static
discharge equipment, such as anti-static wrist straps, when
accessing internal components.
Never touch the ink or wasted ink with bare hands. If ink
comes into contact with your skin, wash it off with soap and
water immediately. If you have a skin irritation, consult a
doctor immediately.
When transporting the printer after installing the ink cartridge,
pack the printer for transportation without removing the ink
cartridge and be sure to secure the Ink Cartridge to the printer
cover with tape tightly to keep it from moving.
Use only recommended tools for disassembling, assembling or
adjusting the printer.
Observe the specified torque when tightening screws.
Apply lubricants as specified. (See Chapter 6
“MAINTENANCE”
(p151) for details.)
Make the specified adjustments when you disassemble the
printer. (See Chapter 5 “ADUJUSTMENT”
(p141) for
details.)
when reassembling the Waste Ink Tube, make sure that the tip
of waste ink tube is placed in the correct position, otherwise
ink may leak.
When using compressed air products; such as air duster, for
cleaning during repair and maintenance, the use of such
products containing flammable gas is prohibited.
