EPSON Stylus CX7300/CX7400/DX7400/NX200/TX200 series/SX200 series/Stylus CX8300/CX8400/DX8400/NX400/TX400 series/SX400 series Revision C
DISASSEMBLY/ASSEMBLY Overview 93
Confidential
Scanner unit
Mechanism
Is glass surface dirty? OK / NG
Is any foreign substance mixed
in the CR movement area?
OK / NG
CR mechanism
Does CR operate smoothly? OK / NG
Does CR operate together with
scanner unit?
OK / NG
Does CR make abnormal noise
during its operation?
OK / NG
LED
Does LED turn on normally?
And is white reflection test done
near home position?
OK / NG
ON-line Test ON-line Test Is the operation normal? OK / NG
Copy Copy Is the local copy action normal? OK / NG
Adjustment
Specified
Adjustment
Are all the adjustment done
correctly
OK / NG
Lubrication
Specified
Lubrication
Are all the lubrication made at
the specified points?
OK / NG
Is the amount of lubrication
correct?
OK / NG
Function ROM Version Version: OK / NG
Packing
Ink Cartridge
Are the ink cartridges installed
correctly?
OK / NG
Waste Ink pad
Are the waste ink pads adequate
to absorb?
OK / NG
Protective materials
Is the printer carriage placed at
the capping position?
OK / NG
Others
Attachments,
Accessories
Have all the relevant items been
included in the package?
OK / NG
Table 4-2. Work Completion Check
Classification Item Check Point Status
To Next Page
