Page #128 background image
128
•A special character is indicated by combining ‘{‘ and the next character.
GS1-128
• ‘()’ is the delimiter for the application identifiers. (printed as the HRI character, but not encoded.)
•The start codes (CODE A, CODE B, CODE C) and the stop code are added automatically.
•A symbol character FNC1, that is described after the start code, is automatically added.
•When '*' is specified, it is skipped.
•2 digits of consecutive numbers m
ust be specified as the application identifier. If it is not specified
correctly, an error occurs.
•A special character is indicated by combining ‘{‘ and the next character.
•When the character right after ‘{‘ is not any of the following, an error occurs.
Control Character ASCII HRI Character
SHIFT {S Not printed.
CODE A {A Not printed.
CODE B {B Not printed.
CODE C {C Not printed.
FNC1 {1 Not printed.
FNC2 {2 Not printed.
FNC3 {3 Not printed.
FNC4 {4 Not printed.
‘{‘ {{ ‘{‘ is printed.
Control Character ASCII HRI Character
Control Character (00h ~ 1Fh, 7Fh) Space is printed.
FNC1 {1 Space is printed.
‘{’ {{ ‘{‘ is printed.
‘(’ {( ‘(‘ is printed.
‘)’ {) ‘)‘ is printed.
‘*’ {* ‘*‘ is printed.
Left parenthesis for the application identifier ( ‘(‘ is printed.
Right parenthesis for the application identifier ) ‘)‘ is printed.
Skipped character * Not printed.
