Epson TM-T20III User Manual

16
Chapter 1 Product Overview
Status and Errors
The LEDs light or flash to indicate the printer status.
Online and Offline
Online
The printer is online and ready for normal printing unless there is a reason to go offline.
Offline
The printer automatically goes offline under the following conditions:
• While the printer power is turning on/off
• While a self-test is running
• While roll paper is fed using the Feed button
• When the printer stops printing due to a paper end
(When the paper end is detected by the roll paper end sensor)
• During an operation standby state
• When an error has occurred ("Status and Errors" on page 16)
• W
hile the roll paper cover is open
Automatically Recoverable Errors
The printer cannot print when automatically recoverable errors occur. When the conditions for recovery
described below are met, the printer automatically recovers from the error.
The printer cannot print while an error is left unsolved.
Error Error description Error LED status Condition for Recovery
Roll paper cover
open error
The roll paper cover was opened
during printing
ON The roll paper cover is closed
Head temperature error A high temperature outside the
thermal head drive operating
range was detected
ON When the thermal head cools

Epson TM-T20III Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum roll diameter	83 mm
Supported paper width	80 mm
USB port	Yes
USB connector	USB Type-B
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Mean cycles between failures (MCBF)	60000000
AC input voltage	24 V
Power consumption	1800 mA
Power source type	AC
Power consumption (standby)	100 mA
Product color	Black
Safety	UL, CSA, TÜV
Certification	FCC-Class A, CE, EN55022-Class A
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	1.5 million cuts
Built-in sensors details	Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	235 mm
Package width	192 mm
Package height	280 mm
Package weight	2620 g
Quantity per pack	1 pc(s)
Ethernet LAN	No
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	295 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Depth	199 mm
Width	140 mm
Height	146 mm
