Epson TM-T20III User Manual

25
Chapter 2 Setup
Hanging the Printer on a Wall
To securely hang the printer on a wall, follow the steps below.
1
Put two screws (diameter: 4 mm {0.16"}, head diameter: 7 to 9 mm {0.28 to 0.35"}) into
the wall at an interval of 80 mm {3.15"}.
Make sure the length of the screw in the wall is 10 mm {0.39"} or more, and the length outside the
wall is 3 to 4 mm {0.12 to 0.16"}.
2
Remove the two screws from the printer, and then attach the wall hanging bracket to
the printer using the screws.
• Hang the printer on a wood, concrete, or metal wall. The thickness of the wall should be 10 mm
{0.4"} or more.
• Be sure to use metallic screws.
• The screws to be put into the wall must have a pull-out strength of 150 N (15.3 kgf) or more.
80 mm
{3.15"}
4 mm
{0.16"}
3 to 4 mm {0.12 to 0.16"}
7 to 9 mm
{0.28 to 0.35"}
10 mm {0.39"} or more
Screws
Wall hanging bracket

Epson TM-T20III Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum roll diameter	83 mm
Supported paper width	80 mm
USB port	Yes
USB connector	USB Type-B
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Mean cycles between failures (MCBF)	60000000
AC input voltage	24 V
Power consumption	1800 mA
Power source type	AC
Power consumption (standby)	100 mA
Product color	Black
Safety	UL, CSA, TÜV
Certification	FCC-Class A, CE, EN55022-Class A
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	1.5 million cuts
Built-in sensors details	Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	235 mm
Package width	192 mm
Package height	280 mm
Package weight	2620 g
Quantity per pack	1 pc(s)
Ethernet LAN	No
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	295 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Depth	199 mm
Width	140 mm
Height	146 mm
