Page #63 background imageLoading...
Page #63 background image
63
Chapter 4 Application Development Information
Controlling the Cash Drawer
A pulse output is sent to drawer kick connector pin 2 or pin 5, and you can open the drawer.
You can also check the open/close status of the drawer by checking the signal level of the drawer kick connector
pin 3.
These controls are executed by a driver or by commands.
ESC/POS Commands
Prepare the output command for the specified pulse and the status transmission command.
For details, see the ESC/POS Command Reference.
For Windows Printer Drivers (APD)
You can set so that the drawer opens at the start/end of printing or start/end of a page. For details,
see the manual for drivers.
For details on control, see the manual for Status API of the driver.
OPOS (OCX Driver)
Register a cash drawer using the SetupPOS Utility, and control using the OpenDrawer method or
the DirectIO function.
For details, see the “EPSON OPOS ADK MANUAL APPLICATION DEVELOPMENT GUIDE
Cash Drawer” and the “UnifiedPOS Specification.
OPOS for .NET
Register a cash drawer using the SetupPOS Utility, and control using the OpenDrawer method or
the DirectIO function.
For details, see the “EPSON OPOS ADK for .NET MANUAL Application Development Guide Cash
Drawer (EPSON Standard)” and the “UnifiedPOS Specification.
Epson ePOS SDK
The output command for the drawer kick pulse and the status transmission command are provided
in each SDK library. For details, see the user's manuals provided with each SDK.
Whether or not pin 2 or pin 5 operates the drawer kick connector depends on the connected
cash drawer.
You can acquire documents regarding the UnifiedPOS from the following link.
https://nrf.com/resources/retail-technology-standards/unifiedpos
