76
Appendix
Appendix
Product Specifications
* : According to our operation conditions. It may differ depending on the usage conditions and product model.
Printing method Thermal line printing
Paper feed speed Approx. 250 mm/s {approx. 7.88"/s}
(continuous paper feeding with the Feed button)
Cutting Method Partial cut (cutting with one point at left uncut)
Interface Serial/USB mode
USB: USB 2.0 Full-speed (12 Mbps)
Serial: RS-232
Wireless LAN: Connects an optional Wireless LAN unit to the
USB connector.
Ethernet model
USB: USB 2.0 Full-speed (12 Mbps)
Ethernet: 10BASE-T/100BASE-TX
Wireless LAN: Connects an optional Wireless LAN unit to the
USB connector.
Buffers Receive buffer 4 KB/45 bytes (selectable using the memory switches)
Downloaded buffer Approx. 12 KB
(both for user-defined characters and downloaded images)
NV graphics data 256 KB
Downloaded graphics data 208 KB
Barcode/two-dimensional symbol/
composite symbol printing
UPC-A, UPC-E, JAN 8 (EAN 8), JAN 13 (EAN 13), CODE 39,
ITF, CODABAR (NW-7), CODE 93, CODE 128, GS1-128,
GS1 DataBar Omnidirectional, GS1 DataBar Truncated,
GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional,
GS1 DataBar Limited, GS1 DataBar Expanded,
GS1 DataBar Expanded Stacked, PDF417, QR CODE,
MaxiCode, Composite Symbology, Aztec Code, DataMatrix
Drawer kick connector drive function 2 drives
Power supply Power supplied by the specified AC adapter
AC power consumption
(100 to 230V/50 to 60 Hz)*
Operating Approx. 29.5 W
Standby Approx. 0.80 W
Life Mechanism 15 million lines
Thermal head 150 km {93.2 miles}
Autocutter 1,500,000 cuts
MTBF 360,000 hours
MCBF 60,000,000 lines
Temperature/humidity Operating: 5 to 45°C {41 to 113°F}, 10 to 90% RH
Storage: -10 to 50°C {14 to 122°F}, 10 to 90% RH
Overall dimensions (H × W × D) 146 × 140 × 199 mm {5.75 × 5.51 × 7.83"}
Mass Approx. 1.7 kg {3.31 lb} (roll paper excluded)
