Epson TM-T20III User Manual

21
Chapter 1 Product Overview
Simple Setup for Wireless LAN
This printer comes with a mode (SimpleAP) that allows printers to connect with a smart device or a computer
without requiring a wireless access point. This allows you to easily setup a wireless LAN for the printer by using
a printer settings tool (TM-T20III Utility, Epson TM Utility for iOS/Android, or EpsonNet Config) even
without a network environment such as access points.
SimpleAP mode is enabled by default when shipping from the factory. When SimpleAP mode is enabled and
the printer is turned on, the following information is printed automatically.
Although operations are performed in SimpleAP mode during the initial startup, operations switch to standard
mode (infrastructure mode) when changing settings in Epson TM-T20III Utility or EpsonNet Config. After
switching, operations continue in standard mode. If you want to make settings in SimpleAP mode again,
initialize the communication settings. ("Resetting the Interface Settings" on page 61)
SimpleAP Start
SSID
Encryption Type
Passphrase
IP Address
MAC Address
: EPSON_Printer
: WPA2-PSK
: 12345678
: 192.168.192.168
: xx-xx-xx-xx-xx-xx
Standard mode
(infrastructure
mode)
SimpleAP mode
(default setting)
Changing to standard mode
Ex.) Change IP address,
change SSID
Initialize the communication
settings

Epson TM-T20III Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum roll diameter	83 mm
Supported paper width	80 mm
USB port	Yes
USB connector	USB Type-B
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Mean cycles between failures (MCBF)	60000000
AC input voltage	24 V
Power consumption	1800 mA
Power source type	AC
Power consumption (standby)	100 mA
Product color	Black
Safety	UL, CSA, TÜV
Certification	FCC-Class A, CE, EN55022-Class A
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	1.5 million cuts
Built-in sensors details	Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	235 mm
Package width	192 mm
Package height	280 mm
Package weight	2620 g
Quantity per pack	1 pc(s)
Ethernet LAN	No
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	295 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Depth	199 mm
Width	140 mm
Height	146 mm
