Chapter 1 Product Overview
29
1
Control Panel
Name Status Description
Power LED
(green)
On Power is being supplied
Off Power is not being supplied
Error LED Off Normal operation (online)
On Immediately after the power is turned on or immediately after a
reset (offline).
Automatically goes off after a while to indicate that the printer is
ready.
The end of the roll paper is detected, and when printing has
stopped (offline). If this happens, replace the roll paper.
Flashing An error has occurred
Paper LED Off There is a sufficient amount of roll paper remaining
On There is little or no roll paper remaining
Flashing A self-test printing standby state and macro execution standby state
Feed button Pressing this button once feeds the roll paper by one line. Holding this button down
feeds the roll paper continuously.
