Adjusting the Roll Paper Near-End Sensor
Below are two situations where a roll paper near-end sensor adjustment is required.
•To adjust the detection position to suit the diameter of the roll paper core used.
•To adjust the detection position of remaining amount of paper.
Follow the steps below to adjust the roll paper near-end sensor.
1
Open the roll paper cover, and remove the roll paper.
2
Loosen the adjustment screw fastening the sensor, and align the upper
edge of the positioning plate with the adjustment position.
 Since roll paper cores vary slightly in shape, depending on roll paper design and
manufacturing tolerances, it is impossible to detect the remaining paper exactly.
 Use roll paper with a core whose inner diameter is 12 mm {0.47"} and outer diameter is
18 mm {0.71"} so that the near-end sensor can detect the remaining paper as accurately
as possible.
Adjustment position
Remaining amount of paper
(outer diameter: mm)
Upper Approx. 27 {1.06"}
Lower (Initial setting) Approx. 23 {0.97"}
