Epson TM-T88V-DT

Chapter 1 Product Overview
39
1
Printing Specifications
dpi: dots per inch
*1: Only for South Asia model
*2: When printing with the default print density level at 24V and 25°C {77°F}.
80 mm width paper printing 58 mm width paper printing
Printing method Thermal line printing
Dot density 180 × 180 dpi
Printing direction Unidirectional with friction feed (Reverse feed is not
supported.)
Printing width 72.0 mm (2.83"), 512 dots 50.8 mm (2.0"), 360 dots
Characters per line Font A (12 × 24) 42 30
Font B (9 × 17) 56 40
Special Font A *
1
(12 × 24)
42 30
Special Font B *
1
(9 × 24)
56 40
Maximum print speed *
2
300 mm/s
Line spacing 4.23 mm {1/6"} (Initial setting)
