Chapter 2 Setup
99
2
3
Set the following, then click [Add].
The information for the registered device is displayed in [Registered printers].
4
Click [Test printing] and check if the registered printer operates properly.
Item Description
Device ID
Set the device ID for the printer you want to register. (Any character
string)
Type Select network printer.
Model no. Select the printer model.
IP address Input the IP address of the printer you want to control.
Retry interval Set the timeout retry interval.
[Operating test] appears if the registered printer is TM-H6000IV, and [Test printing]
appears for printers other than TM-H6000IV.
Clicking [Operating test] displays the "Operating test" screen.
Use the "Operating test" screen to check the printer performance.
For detail, see "Oparating test" on page 135.
To Next Page
