Epson VT6L

Setup & Operation 4. Setting of End Effectors
40 VT Rev.1
4.2 Attaching Cameras and Air Valves
Decks are equipped to Arms #4 and #5 to enable the easy installation of air valve.
To mount the camera, the camera plate unit is necessary.
We provide the optional “Camera Plate Unit”. For details, refer to Setup & Operation: 11.
Options.
Arm #4
Deck
Arm #5
Deck
