Epson WorkForce Pro WF-C579R User Manual

212
1. If you are scanning to a network folder on your computer, do one of the following to check the format
of your computer name:
• Windows 10 or Windows 8.x: Hold down the Windows key on your keyboard and press the X
key. Select System from the list that appears. Check the Computer Name or Device Name listed
for your computer on the System window.
• Windows 7: Click , right-click Computer, and select Properties. Check the Computer Name
listed for your computer on the System window.
Note: The settings in these steps may vary, depending on your version of Windows. See Windows
Help for details on your operating system.
2. If the computer's name uses any characters that are not alphanumeric (letters or numbers), do one
of the following to change the computer's name:
• Windows 10 or 8.x: Select Rename this PC and follow the on-screen prompts.
• Windows 7: Select Change Settings, change the computer's name, and click OK. (See Windows
Help for instructions, if necessary.)
Note: You need to be logged into Windows as an administrator to change the computer's name.
After changing the name, restart your computer.
3. Start File Explorer or Windows Explorer.
4. Create a folder on the Windows desktop with a folder name of 12 characters or less; otherwise, your
product may not be able to access the folder.
Note: You need to be logged into Windows as an administrator to access the desktop folder and the
document folder under each User folder.
5. Right-click the folder you created and select Properties.
6. On the General tab, deselect the Read-only checkbox to allow users to access the folder over the
network.
7. Select the Sharing tab and click the Advanced Sharing button.
Note: You need to be logged into Windows as an administrator to select the Advanced Sharing
button.
8. On the Advanced Sharing screen, select the Share this folder checkbox.

Epson WorkForce Pro WF-C579R Specifications

General

Secure printing	Yes
Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	4.8 s
Time to first page (color, normal)	5.3 s
Print speed (black, draft quality, A4/US Letter)	34 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (color, normal quality, A4/US Letter)	15 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Scan to	Cloud
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	-
Fax memory	550 pages
Modem speed	33.6 Kbit/s
Fax forwarding to	E-mail, Folder, PC
Fax transmission speed	3 sec/page
Fax speed dialing (max numbers)	200
Printing colors	Black, Cyan, Yellow, Magenta
Country of origin	Indonesia
Maximum duty cycle	50000 pages per month
Recommended duty cycle	400 - 4500 pages per month
Page description languages	PCL 5c, PCL 6, ESC/P-R, PostScript 3, PDF 1.7
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	4.3 \
Market positioning	Business
Email protocols	POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security features	Access restriction with Epson Web Config, Confidential and secure PIN-enabled printing, LDAP Address Book, IPsec, IEEE802.1x, SSL (Server Authentication), Admin panel mode
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA-TKIP, WPA2-PSK, WPA2-AES, WPA2-Enterprise
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Epson Connect, Epson iPrint, Epson Email Print, Epson Remote Print, Apple AirPrint, Google Cloud Print
Supported network protocols (IPv4)	LPD, HTTPS, HTTP, DHCP, AR
Supported network protocols (IPv6)	LPD, WSD-Print, WSD-Scan, IPSEC
Paper input type	Paper tray
Total input capacity	830 sheets
Total output capacity	150 sheets
Maximum input capacity	1330 sheets
Total number of input trays	3
Multi-Purpose tray input capacity	80 sheets
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	C5, C6
Custom media width	100 - 215.9 mm
Custom media length	148 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper, Art paper, Letterhead
Paper tray media weight	64 - 256 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
USB connector	USB Type-A
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	2
Internal memory	- MB
Sound power level (printing)	6.7 dB
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (ready)	14 W
Power consumption (copying)	29 W
Power consumption (PowerSave)	1.3 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.2 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Pallet width	800 mm
Pallet height	2055 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pallet	2 pc(s)
Harmonized System (HS) code	84433100
Package depth	621 mm
Package width	580 mm
Package height	845 mm
Package weight	31880 g
Quantity per pack	1 pc(s)
Printing method	Epson PrecisionCore
Print head nozzles	800 nozzles black, 800 nozzles per colour
Supported network protocols	TCP/IPv4, TCP/IPv6, HTTP, HTTPS, IPSEC
Compatible operating systems	Citrix XenApp 7.6 und höher, Citrix XenDesktop Version 7.6, Linux, Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X 10.11.x, Mac OS X 10.12.x, Mac OS X 10.6.8 or later, Windows 10, Windows 7, Windows 7, 64-Bit-Version, Windows 8, Windows 8 (32/64 Bit), Windows 8.1, Windows 8.1 x64 Edition, Windows Server 2003 R2 x64, Windows Server 2008 (32/64 Bit), Windows Server 2008 R2, Windows Server 2012 (64bit), Windows Server 2012 R2, Windows Server 2016, Windows Vista, Windows Vista (32/64 Bit), Windows Vista, 64-Bit-Version, Windows XP SP2 oder höher, Windows XP SP3, Windows XP, 64-Bit-Version, Windows Server 2003 R2, Windows XP Professional x64 Edition, XP Professional x64 Edition SP2
Other network protocols supported	WSD-Scan, FTP
Cables included	AC

Weight and Dimensions

Depth	535 mm
Width	425 mm
Height	513 mm
