7 • Disassembly, Cleaning and Disinfection
80110-801_V23493  2022-03
Chapter 7
Disassembly, Cleaning and Disinfection
Removal of separating medium; disassembly of ESM 2 suction unit,
applicator, and pump unit
Removing separating medium
Remove the separating medium from the pump unit. Dispose of the separating medi-
um.
Detaching the suction hose from
the suction bag
1. Disconnect the suction hose of the applicator from the suction bag (no picture).
Fig. 7-1
2. Remove the adapter and attach the adapter to the plug and connector on the top
(I.) intended for this purpose.
3. Use the cap (II.) to close the connection for the suction hose.
Removing the suction bag
Fig. 7-2
 Remove the suction bag from the suction container and dispose of the suction bag
in a suitable way.
WARNING
Contaminated accessories
Risk of infection for the medical staff.
 Wear gloves when dismantling the accessories
I.
II.
