EDA 2530 Commissioning Procedure for Cable and Wireless Access
1/153 22-FGC 101 0239/2 Uen Rev J 2010-04-01
© Ericsson AB 2010
Commercial in confidence
26 (200)
Note: This unit occupies two slots in the upper shelf and is fitted above the 64 x
ADSL2+ unit (In Even Slot 2) and the optional associated 64 x POTS/VoIP unit (In
Odd Slot 3). This unit will be fitted in slots 2 and 3, 4 and 5, 6 and 7, 8 and 9, 10
and 11, 12 and 13, 14 and 15, 16 and 17, 18 and 19 as required. IMPORTANT: If
the POTS/VoIP unit is fitted then the POTS connectors MUST NOT
be used
COMBO Card DIN Connector Pin Designations
SIGNAL PIN SIGNAL PIN
Line 1 a/b 1a 2a Line 33 a/b 1c 2c
Line 2 a/b 3a 4a Line 34 a/b 3c 4c
Line 3 a/b 5a 6a Line 35 a/b 5c 6c
Line 4 a/b 7a 8a Line 36 a/b 7c 8c
Line 5 a/b 9a 10a Line 37 a/b 9c 10c
Line 6 a/b 11a 12a Line 38 a/b 11c 12c
Line 7 a/b 13a 14a Line 39 a/b 13c 14c
Line 8 a/b 15a 16a Line 40 a/b 15c 16c
Line 9 a/b 17a 18a Line 41 a/b 17c 18c
Line 10 a/b 19a 20a Line 42 a/b 19c 20c
Line 11 a/b 21a 22a Line 43 a/b 21c 22c
Line 12 a/b 23a 24a Line 44 a/b 23c 24c
Line 13 a/b 25a 26a Line 45 a/b 25c 26c
Line 14 a/b 27a 28a Line 46 a/b 27c 28c
Line 15 a/b 29a 30a Line 47 a/b 29c 30c
Line 16 a/b 31a 32a Line 48 a/b 31c 32c
Line 17 a/b 1b 2b Line 49 a/b 1d 2d
Line 18 a/b 3b 4b Line 50 a/b 3d 4d
Line 19 a/b 5b 6b Line 51 a/b 5d 6d
Line 20 a/b 7b 8b Line 52 a/b 7d 8d
Line 21 a/b 9b 10b Line 53 a/b 9d 10d
Line 22 a/b 11b 12b Line 54 a/b 11d 12d
Line 23 a/b 13b 14b Line 55 a/b 13d 14d
Line 24 a/b 15b 16b Line 56 a/b 15d 16d
Line 25 a/b 17b 18b Line 57 a/b 17d 18d
Line 26 a/b 19b 20b Line 58 a/b 19d 20d
Line 27 a/b 21b 22b Line 59 a/b 21d 22d
Line 28 a/b 23b 24b Line 60 a/b 23d 24d
Line 29 a/b 25b 26b Line 61 a/b 25d 26d
Line 30 a/b 27b 28b Line 62 a/b 27d 28d
Line 31 a/b 29b 30b Line 63 a/b 29d 30d
Line 32 a/b 31b 32b Line 64 a/b 31d 32d
Table 2.3 – DIN Connector Pinout for 64 x COMBI Interface + I/O POTS + TAM
ETSI Connection Unit (02HAT00282AAQ)
