ESAB EMS215IC/EMP215IC
Manual 0463 413 001 TROUBLESHOOTING 6-19
The following image shows the previous steps (4a and 4b) listed. In the oval you will see the step number and
below that the meter reading you should see.
4a
Approximately 12k ohm
CN7
4b
Approximately 12k ohm
